Sakai SV204D vibratory 54 inch single drum 5 ton soil compactor with traction control, lug tires, and a Kubota diesel engine.
SV204D soil compactor operator step and operating deck.
Side view of the SV204D smooth drum vibratory soil roller with ROPS not installed.
Rear of Sakai SV204D vibratory 5 ton soil compactor showing the raised exhaust for trench compaction work.
SV204D soil compactor operator dash panel showing parking brake, light switch etc.
Sakai SV204D soil compactor lug or tractor style tires as standard equipment.
Sakai SV204D 5 ton soil roller with front vibratory drum articulated.
SV204D soil roller dash panel showing the vibratory mode selector switch with on demand button, offf, and continuous modes.
SV204D soil roller switch panel showing diesel after treatment lights and regen switch.
SV204D dash panel engine warning, engine stop, and over heat lights.
Sakai SV204D smooth drum vibratory soil roller with tractor lug tires and no ROPS installed.
SV204D soil compactor forward neutral reverse lever on the operator deck.

RELIABLE. EASY-TO-USE. DURABLE.

  • 54"
  • 10,220 lbs
  • 73 HP Kubota

Features & Benefits:

  • High centrifugal force outputs
  • Several amplitude and frequency setting combinations
  • All vibration controls at instrument panel
  • Heavy duty center hitch design
  • Superior shock isolation system
  • Independent drum vibration
  • ROPS and seat belt
  • Raised exhaust for trench work
  • Limited-slip hydraulic drive, a no-slip axle, and tractor tires combine to optimize traction
  • Standard safety equipment: ROPS, retractable seat belt, horn, backup alarm, operator deck hand rails, electric parking brake w/ interlock, & foot brake

Specifications

DRUM
Type Smooth Single Drum
Size (w x d) 54″ x 39″ | 1,370mm x 1,000 mm
OPERATING
Weight 10,220 lbs | 4,635 kg
Gradability 52%
VIBRATION
Frequency 1,800 vpm | 30 Hz
Centrifugal Force 16,635 lbs | 74 kN
Nominal Amplitude .065 ins | 1.65 mm
ENGINE
Make & Model Kubota Tier 4F V3307-CR-T-EF05 (Diesel)
Horsepower 73 Hp @ 2200 rpm | 54.6 kW @ 2200 min-1
BRAKING
Systems Hydrostatic Service Brake + SAHR + Combined Footbrake

OPTIONS
